frame prefabricated warehouse with brick wall for sale
1. The design of WELLCAMP, WELLCAMP prefab house, WELLCAMP container house cheap prefab warehouse follows a basic set of principles. These principles include rhythm, balance, focal point & emphasis, color, and function.
2. Our prefabricated warehouse is characterized by high performance and stable quality.
3. The application of prefabricated warehouse is more and more popular because it has features like cheap prefab warehouse .
4. Customization service for our prefabricated warehouse is available.
5. The product is superior in the field and has a large market share.
| Sort | Name | Specification |
Size | Length | 76.61m |
| Width | 18.76m | |
| Height | 6m | |
| Total area | 1437.2m2 | |
Steel structure | Column | "H" section steel |
| Beam | "H" section steel | |
| Purlin | “C” section steel | |
Panel | Wall panel | 0.426mm single steel sheet |
| Roof panel | 0.426mm single steel sheet | |
Accessories | Window | 1200*925 aluminum sliding window |
| Door | Electric roller door | |
This steel structure building is used as the warehouse in Uganda. Ventilation balls are installed for the air flow on the top of the warehouse.
To keep safer and avoid the water to come inside, it needs to build a one-meter high wall before installing the wall panel.
◪1.The structure is strong “H” section steel and “C” section steel. |
◪2.Single steel sheet or sandwich panel for the wall and roof. |
◪3.Normally requires cement foundation of 600mm at least. |
◪ 4.The height of the brick or concrete wall from 1m to 2m is suggested, for a better waterproofing performance before installing prefabricated wall panels. waterproofing performance before installing prefabricated wall panels. |
◪ 5.All the steel structure is painted and anti-rust which can be normally used for more than 30 years without any building wastes. |
◪ 6.Easy to build. The building is connected by bolts and screws. 6 labors constitute one team, can install areas of 300 square meters each day. |
Workshop 3D model
Material parameters
Main steel："H" section steell for column & beam；
Wall panel：0.426mm single steel sheet；
Roof panel：0.426mm single steel sheet；
Window：Aluminum sliding window；
Door：Electric roller door；
Ridge capping:0.426mm single steel sheet.
Wind resistance: | Grade 11 |
Earthquake resistance: | Grade 7 |
Snow load capacity of roofing: | 0.6 kn/㎡ |
Live load capacity of roofing: | 0.6 kn/㎡ |
External and internal wall heat transmission coefficient: | 0.35 kcal/㎡hc |
Wall permitted loading: | 0.6 kn/㎡ |
Wall and roof panel: | EPS/IEPS/ROCK WOOL/PU |
Thickness of the wall and roof: | 50mm/75mm/100mm |
Delivery time: | Normally 20-25 days |
Container loading(50mm): | 900㎡/HQ |
This workshop can be used as the dormitory, office, school, canteen, store room, shop, clinic and so on. The materials of the house are very environment-friendly. It can be assembled and disassembled 6 times. For more information about it, welcome to contact us.
Company Features
1. Guangdong WELLCAMP BUILDING MATERIALS CO., LTD is highly recommended by many customers for its high quality prefabricated warehouse.
2. Guangdong WELLCAMP BUILDING MATERIALS CO., LTD has successfully got several patents for technology.
3. cheap prefab warehouse is the core concept of Guangdong WELLCAMP BUILDING MATERIALS CO., LTD's pursuit. Contact us! prefab warehouse has been the driving force for Guangdong WELLCAMP BUILDING MATERIALS CO., LTD since its establishment. Contact us! Cooperating with customers to promote steel warehouse manufacturing industry better is our wish. Contact us!
