WELLCAMP, WELLCAMP prefab house, WELLCAMP container house three floor prefab guest house apartment for hospital
1. WELLCAMP, WELLCAMP prefab house, WELLCAMP container house china prefabricated house suppliers is professionally designed. Its design is based on outdoor environmental conditions, user preferences and the attractiveness of the building's exterior. Its stable quality is achieved by the efforts of the design team, engineer team, innovation team, and QC team
2. [企业简称] has a team of professional engineers with rich experience in design, production and installation. In addition, we have introduced advanced production equipment. All this provides favorable conditions for producing prefab guest house with excellent performance and high quality.
3. prefab guest house has quickly developed with the good products performance. The product is wind-resistant and can withstand more pressure
| Sort | Name | Specification |
Size | Length | 32.92m |
| Width | 12.9m | |
| Height | 5.7m | |
| Total area | 849.34m2 | |
Steel structure | Column | "C" section steel |
| Beam | "C" section steel | |
| Purlin | "C" section steel | |
Panel | Wall panel | 50mm EPS sandwich panel |
| Roof panel | 50mm EPS sandwich panel | |
Accessories | Window | Aluminium alloy sliding window |
| Door | Double opening steel Door outside and sandwich door inside | |
| Payment terms | T/T,L/C | |
| MOQ | 200 square meter | |
Qatar Project. This prefabricated house is built for the workers' dormitories. There are middle walkway and two siding rooms.
OOne building has 36 rooms. One room has the capacity of 6-8 labors, serving double bed.
◪1. The unit figure for K house dimension is K. 1k=1.82m |
◪2. K house can be done as 1 floor, 2 floors or 3 floors building.Figures for house with different stories: One floor=3P, two floors=6p, three floors = 9p (1P=0.95m ). |
◪3. K house is commonly used with qualified waterproof, fireproof （EPS/Rock wool/IEPS/PU sandwich panel）, heat insulation and sound insulation performance. |
◪ 4. K house uses reusable materials and is more environment-friendly compared to traditional buildings. It can be assembled and disassembled 6 times. |
◪ 5. K house is anti-worm and ant. All steel structures are well painted and anti-rust which can be normally used for over 15 years with a very limited amount of building wastes. |
◪ 6. K house only requires level concrete floor for the foundation. |
◪ 7. 6 labors constitute one team, which can install areas of more than 300 ㎡ each day. |
K-House 3D model
Material parameters
Main steel：C section steel for column& beam；
Wall panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Roof panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Window：Aluminum sliding window；
Door：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel or steel door；
Ridge capping: 0.326/0.376/0.426mm single steel sheet.
Wind resistance | Grade 11(wind speed≤120 km/h) |
Earthquake resistance | Grade 7 |
Snow load capacity of roofing | 0.6 kn/m² |
Live load capacity of roofing | 0.6 kn/m² |
External and internal wall heat transmission coefficient | 0.35 kcal/m²hc |
Wall permitted loading | 0.6 kn/m² |
Second floor load capacity | 180kg/m² |
Live load of corridor | 2.5kn/m² |
Density of EPS | 12 kg/m² |
Delivery time | Normally 20-25 days |
Container loading | 300-320 m² /HQ |
This prefab house can be used as the dormitory, office, school, canteen, store room, shop, clinic and so on. The materials of the house are very environment-friendly. It can be assembled and disassembled 6 times. For more information about it, welcome to contact us.
