economic prefab container homes classroom for dormitory
1. prefab container homes has a simple and flexible overall structure. It greatly improves the transportation efficiency and conforms to the modern environmental protection and energy saving concept.
2. The product has successfully achieved customer satisfaction and has broad market application prospects. It is highly evaluated by customers around the world, such as the Middle East, Africa, and Southeast Asia
3. The product is highly sanitary. It has a non-porous and clean surface area that will not nurture germs or infections. It can be freely combined with other products to maximize the space
4. The product is eco-friendly. Run on clean solar energy, it produces zero emission, as it does not utilize non-renewable resources and burn fuel. It is made of environmentally-friendly materials to protect the ecological system
| Sort | Name | Specification |
Size | Length | 15.2m |
| Width | 5.7m | |
| Height | 6m | |
| Total area | 188.48 m² | |
Steel structure | Column | Square tube |
| Beam | Square tube | |
| Purlin | "C" section steel | |
Panel | Wall panel | 50mm EPS sandwich Panel |
| Roof panel | 50mm EPS sandwich Panel | |
Accessories | Window | 1200*930 aluminum sliding window |
| Door | EPS sandwich door | |
Two-floor Prefabricated Steel Building. This steel building is built for workers' accommodation with totally 8 rooms.
All the steel structures are hidden inside with modern and good looking designs. China prefabricated home.
◪1.The unit figure for T house dimension is T. 1T=0.95m. |
◪2.T house can be done as 1 floor, 2 floors or 3 floors building. |
◪3The T house has a better looking and modern design. All the steel structures are hidden inside. |
◪ 4.T house features with good waterproof, fireproof, heat insulation and sound insulation performance. |
◪ 5.T house use reusable materials and is more environment-friendly compared to traditional buildings. It can be assembled and disassembled six times. |
◪ 6.T house is anti-worm and ant. All the steel structures are well painted and anti-rust which can be normally used for more than 20 years without any building garbage. |
◪ 7. T house only requires level concrete floor for the foundation. |
◪ 8. Easy installation. The house is connected by screws and bolts. It can be assembled and disassembled 6 times. be assembled and disassembled 6 times. |
◪ 9.6 labors constitute one team, which can install areas of more than 300 ㎡ each day. |
T-House 3D model
Material parameters
Main steel：Square tube for column&beam；
Wall panel：50mm EPS Sandwich panel；
Roof panel：50mm EPS Sandwich panel；
Window：Aluminum sliding window；
Door：EPS sandwich door；
ridge capping： 0.326/0.376/0.426mm single steel sheet.
Wind resistance: | Grade 11 |
Earthquake resistance: | Grade 7 |
Snow load capacity of roofing: | 0.6 kn/m2 |
Live load capacity of roofing: | 0.6 kn/㎡ |
External and internal wall heat transmission coefficient: | 0.35 kcal/㎡hc |
Wall permitted loading: | 0.6 kn/㎡ |
Second floor load capacity: | 180kg/㎡ |
Live load of corridor: | 2.5kn/㎡ |
Density of Rock wool: | 60 kg/㎡ |
Density of PU: | 40 kg/㎡ |
Density of EPS: | 12 kg/㎡ |
Density of IEPS: | 20kg/㎡ |
Delivery time: | Normally 20-25 days |
Container loading: | 300㎡ |
This prefab house can be used as the dormitory, office, school, canteen, store room, shop, clinic and so on. The materials of the house are very environment-friendly. It can be assembled and disassembled 6 times. For more information about it, welcome to contact us.
