panel prefabricated shipping container homes classroom for office
1. WELLCAMP, WELLCAMP prefab house, WELLCAMP container house prefabricated house wholesaler is professionally designed. It is created by our designers who master the elements and principles of design, color theory, basic garment silhouettes, as well as garment styling & details. Its stable quality is achieved by the efforts of the design team, engineer team, innovation team, and QC team
2. As a modern approach to marketing, this product is indeed working by netting more potential buyers who respond to the beautiful product promotional presentations. The product has a good bearing capacity which is shock-resistant
3. The product features strong weather resistance. It is able to hold up when exposed to heat, cold, rain and snow. The service life of the product is more than 20 years
| Sort | Name | Specification |
Size | Length | 8.5m |
| Width | 4.3m | |
| Height | 2.8m | |
| Total area | 36.554m2 | |
Steel structure | Column | Square tube |
| Beam | Square tube | |
| Purlin | "C" section steel | |
Panel | Wall panel | 50mm EPS sandwich panel+PVC decoration sheet outside |
| Roof panel | 50mm EPS sandwich panel | |
Accessories | Window | Aluminium alloy sliding window |
| Door | Stee door | |
China Local Light Steel Villa Project. This villa apartment inside has the one toilet, one bed and one table.
This kind of steel villa is very suitable for the resort. It provides an easy installation and a good looking with the competitive price.
◪1.The unit figure for T house dimension is T. 1T=0.95m. |
◪2.T house can be done as 1 floor, 2 floors or 3 floors building. |
◪3.The T house has a better looking and modern design. All the steel structures are hidden inside. |
◪ 4.T house features with good waterproof, fireproof, heat insulation and sound insulation performance. |
◪ 5.TT house use reusable materials and is more environment-friendly compared to traditional buildings. It can be assembled and disassembled six times. |
◪ 6.T house is anti-worm and ant. All the steel structures are well painted aand anti-rust which can be normally used for more than 20 years without any building garbage. |
◪ 7.T house only requires level concrete floor for the foundation. |
◪ 8.Easy installation. The house is connected by screws and bolts. It can be assembled and disassembled 6 times. |
◪ 9.6 labors constitute one team, which can install areas of more than 300 ㎡ each day. |
T-House 3D model
Material parameters
Main steel：C section steel for column & beam；
Wall panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Roof panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Window：Aluminum sliding window；
Door：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel or steel door；
Ridge capping： 0.326/0.376/0.426mm single steel sheet.
Wind resistance: | Grade 11 |
Earthquake resistance: | Grade 7 |
Snow load capacity of roofing: | 0.6 kn/㎡ |
Live load capacity of roofing: | 0.6 kn/㎡ |
External and internal wall heat transmission coefficient: | 0.35 kcal/㎡hc |
Wall permitted loading: | 0.6 kn/㎡ |
Second floor load capacity: | 180kg/㎡ |
Live load of corridor: | 2.5kn/㎡ |
Density of Rock wool: | 60 kg/㎡ |
Density of PU: | 40 kg/m2 |
Density of EPS: | 12 kg/㎡ |
Density of IEPS: | 20kg/m/2 |
Delivery time: | Normally 20-25 days |
Container loading: | 300㎡ |
This prefab house can be used as the dormitory, office, school, canteen, store room, shop, clinic and so on. The materials of the house are very environment-friendly. It can be assembled and disassembled 6 times. For more information about it, welcome to contact us.
Company Features
1. High quality of prefabricated shipping container homes helps Guangdong WELLCAMP BUILDING MATERIALS CO., LTD occupy big global market.
2. Guangdong WELLCAMP BUILDING MATERIALS CO., LTD has a group of highly skilled engineers to provide the best solution on prefab shipping container homes .
3. T prefabricated House is one of the reason that customers choose WELLCAMP, WELLCAMP prefab house, WELLCAMP container house. Inquire online!
