WELLCAMP, WELLCAMP prefab house, WELLCAMP container house delicated prefabricated houses container for accommodation
1. WELLCAMP, WELLCAMP prefab house, WELLCAMP container house prefabricated houses container is designed in accordance with the industry conditions.
2. prefab container homes for sale is made from eco-friendly, non-toxic and odorless materials. With high utilization rate of waste, it meets the requirements of sustainable development. In addition, it has firm structure, high stability, and good bearing capacity and has excellent seismic performance and windproof property.
3. prefab container homes for sale , made from superior materials, has unique effects such as earthquake resistance, fire prevention, heat preservation, and heat insulation. It based on high utilization rate and re-usability makes a great contribution to environmental protection and energy saving.
4. According to the requirements of quality management system, each prefab container homes for sale has been tested strictly before package.
| Sort | Name | Specification |
Size | Length | 15.2m |
| Width | 23.75m | |
| Height | 5.7m | |
| Total area | 207.58m2 | |
Steel structure | Column | Square tube |
| Beam | Square tube | |
| Purlin | "C" section steel | |
Panel | Wall panel | 50mm Glass wool sandwich Panel |
| Roof panel | 50mm Glass wool sandwich Panel | |
Accessories | Window | Aluminium alloy sliding window |
| Door | Eps sandwich panel door | |
Thailand Project. This mobile prefab steel house was built in the construction site for the workers' dormitory.
This mobile prefab steel house covers an area of 207.58㎡, allowing 136 people to live in. 4 people share one room whose roof is decorative with the sheet.
◪1.The unit figure for T house dimension is T. 1T=0.95m. |
◪2.T house can be done as 1 floor, 2 floors or 3 floors building. |
◪3.The T house has a better looking and modern design. All the steel structures are hidden inside. |
◪ 4.T house features with good waterproof, fireproof, heat insulation and sound insulation performance. |
◪ 5.T house use reusable materials and is more environment-friendly compared to traditional buildings. It can be assembled and disassembled six times. |
◪ 6.T house is anti-worm and ant. All the steel structures are well painted and anti-rust which can be normally used for more than 20 years without any building garbage. |
◪ 7.T house only requires level concrete floor for the foundation. |
◪ 8.Easy installation. The house is connected by screws and bolts. It can be assembled and disassembled 6 times. |
◪ 9.6 labors constitute one team, which can install areas of more than 300 ㎡ each day. |
T-House 3D model
Material parameters
Main steel：square tube for column & beam；
Wall panel：50mm rock wool Sandwich panel；
Roof panel：50mm rock wool Sandwich panel；
Window：Aluminum sliding window；
Door：EPS sandwich door；
Ridge capping:Decoration sheet for the roof(Glazed tile).
Wind resistance: | Grade 11 |
Earthquake resistance: | Grade 7 |
Snow load capacity of roofing: | 0.6 kn/㎡ |
Live load capacity of roofing: | 0.6 kn/㎡ |
External and internal wall heat transmission coefficient: | 0.35 kcal/㎡hc |
Wall permitted loading: | 0.6 kn/㎡ |
Second floor load capacity: | 180kg/㎡ |
Live load of corridor: | 2.5kn/㎡ |
Density of Rock wool: | 60 kg/㎡ |
Density of PU: | 40 kg/㎡ |
Density of EPS: | 12 kg/㎡ |
Density of IEPS: | 20kg/㎡ |
Delivery time: | Normally 20-25 days |
Container loading: | 300㎡ |
This prefab house can be used as the dormitory, office, school, canteen, store room, shop, clinic and so on. The materials of the house are very environment-friendly. It can be assembled and disassembled 6 times. For more information about it, welcome to contact us.
Company Features
1. By virtue of professional team and prefabricated houses container , Guangdong WELLCAMP BUILDING MATERIALS CO., LTD is opening wider market for its prefab container homes for sale .
2. Imported advanced machine are equipped to guarantee the bulk production of T prefabricated House .
3. To implement sustainability, we constantly seek new and innovative solutions to minimize the ecological impact of our products and processes during production. Our business philosophy is that we will win our customers' trustworthy by ensuring quality, safety, and sustainability in our business and helping them gain a competitive advantage.
