WELLCAMP, WELLCAMP prefab house, WELLCAMP container house prefabricated warehouse supplier for chicken shed3
1. Guangdong WELLCAMP BUILDING MATERIALS CO., LTD has been dedicated to the research and development of special prefabricated warehouse materials to meet the needs of global customers. The material of the product can be recycled
2. Some of the buyers say this product has helped improve the building structure that has been constructed to last for many years while still strong. It is made of environmentally-friendly materials to protect the ecological system
3. The product has standard height and length measurements and as such, it provides modular elements that can be combined into larger structures. Its outer appearance is characterized by vivid color
4. It comes with mobility. It is designed to be easily transportable and in compliance with the required dimension to ensure that these can be transported anywhere. The product is easy to move and install
| Sort | Name | Specification |
Size | Length | 48.61m |
| Width | 18.76m | |
| Height | 6m | |
| Total area | 911.93m2 | |
Steel structure | Column | H beam |
| Beam | H beam | |
| Purlin | c section steel | |
Panel | Wall panel | 50mm EPS sandwich panel |
| Roof panel | 50mm EPS sandwich panel | |
Accessories | Window | 1500*930 Aluminum sliding window |
| Door | Electric roller door, steel sliding door | |
◪1.The structure is strong “H” section steel and “C” section steel. |
◪2.Single steel sheet or sandwich panel for the wall & roof. |
◪3.Normally requires cement foundation of 600mm at least. |
◪ 4.The height of the brick or concrete wall from 1m to 2m is suggested, for a better waterproofing performance before installing prefabricated wall panels. |
◪ 5.All the steel structure is painted and anti-rust which can be normally used for more than 30 years without any building wastes. |
◪ 6. Easy to build. The building is connected by bolts and screws. 6 labors constitute one team, can install areas of 300 square meters each day. |
Workshop 3D model
Material parameters
Main steel：C section steel for column & beam；
Wall panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Roof panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Window：Aluminum sliding window；
Door：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel or steel door；
Ridge capping： 0.326/0.376/0.426mm single steel sheet.
Wind resistance: | Grade 11 |
Earthquake resistance: | Grade 7 |
Snow load capacity of roofing: | 0.6 kn/㎡ |
Live load capacity of roofing: | 0.6 kn/㎡ |
External and internal wall heat transmission coefficient: | 0.35 kcal/㎡hc |
Wall permitted loading: | 0.6 kn/㎡ |
Wall and roof panel: | EPS/IEPS/ROCK WOOL/PU |
Thickness of the wall and roof: | 50mm/75mm/100mm |
Delivery time: | Normally 20-25 days |
Container loading(50mm): | 300㎡/HQ |
This workshop can be used as the dormitory, office, school, canteen, store room, shop, clinic and so on. The materials of the house are very environment-friendly. It can be assembled and disassembled 6 times. For more information about it, welcome to contact us.
Company Features
1. Guangdong WELLCAMP BUILDING MATERIALS CO., LTD plays a leading role in the scientific research and technological strength
2. Our mission is to create value and make a difference and endeavor to offer customers the lowest possible prices with premium quality. Inquiry!
