WELLCAMP, WELLCAMP prefab house, WELLCAMP container house steel sheds supplier for cow shed
1. The unique function of steel sheds is well received by the customers. The design of the product is a blend of simplicity and utility
2. People commonly think that the product is able to help to increase the appearance and value of the building. All its steel bars have anti-rust treatment, which can provide long-term durability
3. steel sheds takes steel structure as the skeleton and high-quality steel as the enclosing material. It not only has good wind and earthquake resistance, but also has the advantages of heat insulation and water resistance. It can bring people a comfortable living environment.
| Sort | Name | Specification |
Size | Length | 55m |
| Width | 24m | |
| Height | 6m | |
| Total area | 1296m2 | |
Steel structure | Column | H Beam |
| Beam | H Beam | |
| Purlin | C section steel | |
Panel | Wall panel | 0.426 Color Steel Sheet/50mm EPS/50mm PU sandwichpanel |
| Roof panel | 0.426 Color Steel Sheet/50mm EPS/50mm PU sandwichpanel | |
Accessories | Window | Aluminum sliding window |
| Door | Steel sliding door/Electric rolling door | |
◪1.Strong “H”section steel and “C” section steel for the structure. |
◪2.Single steel sheet or sandwich panel for the wall & roof. |
◪3.Normally requires cement foundation of 600mm at least. |
◪ 4.Brick or concrete wall of height from 1m to 2m are suggested for better water proofing performance before installing prefabricated wall panels. |
◪ 5.All the steel structure is painted and anti-rust which can be normally used for more than 30 years without any building wastes. |
◪ 6.Easy to build. The building is connected by bolts and screws. 6 labors one team, each day can install 300 square meter. |
Cowshed 3D model
Material parameters
Main steel：C section steel for column&beam；
Wall panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Roof panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Window：Aluminum sliding window；
Door：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel or steel door；
ridge capping： 0.326/0.376/0.426mm single steel sheet.
Wind resistance: | Grade 11 |
Earthquake resistance: | Grade 7 |
Snow load capacity of roofing: | 0.6 kn/m2 |
Live load capacity of roofing: | 0.6 kn/m2 |
External and internal wall heat transmission coefficient: | 0.35 kcal/m2hc |
Wall permitted loading: | 0.6 kn/m2 |
Wall and roof panel: | EPS/IEPS/ROCK WOOL/PU |
Thickness of the wall and roof: | 50mm/75mm/100mm |
Delivery time: | Normally 20-25 days |
Container loading(50mm): | 300m2/HQ |
This cowshed can be used as the dormitory,office,school,canteen,store room,shop,clinic and so on, The materials of the house is very environment friendly. It can be assemed and disassemed for six times. More information about it, welcome to contact us.
Company Features
1. Guangdong WELLCAMP BUILDING MATERIALS CO., LTD is widely known as experienced and professional manufacturer for steel sheds. The quality of steel shed can be assured by our professional technicians.
2. To satisfy the needs of developing WELLCAMP, WELLCAMP prefab house, WELLCAMP container house, it has constantly introduced high technology to manufacture steel structure .
3. Guangdong WELLCAMP BUILDING MATERIALS CO., LTD has a sound management system, strong technical force and the advanced production equipment. Leading the stainless steel shed industry has always been the goal of WELLCAMP, WELLCAMP prefab house, WELLCAMP container house. Check it!
