WELLCAMP, WELLCAMP prefab house, WELLCAMP container house three floor china prefabricated house manufacturer for hospital
1. WELLCAMP, WELLCAMP prefab house, WELLCAMP container house china prefabricated house manufacturer complies with all kinds of certifications. They may include CE certificate, UL certificate, CCC certificate, and CB certificate.
2. The product is efficient in solar light absorption. The powder-coated exterior of the product allows it to absorb nearly all of the solar spectrum.
3. It is highly resistant to chemical corrosion. It is electrostatically sprayed with the powder paint to form a thick layer which can protect the surface from corrosion.
4. Guangdong WELLCAMP BUILDING MATERIALS CO., LTD is able to provide customers around the world with internationally-advanced technology and support.
5. The popularity of WELLCAMP, WELLCAMP prefab house, WELLCAMP container house also benefits from the implement of quality assurance and high-quality service.
| Sort | Name | Specification |
Size | Length | 10K(18.36m) |
| Width | 3K(5.62m) | |
| Height | 6P | |
| Total area | 242.91 m² | |
Steel structure | Column | "C" section steel |
| Beam | "C" section steel | |
| Purlin | "C" section steel | |
Panel | Wall panel | 50mm EPS sandwich panel |
| Roof panel | 50mm EPS sandwich panel | |
Accessories | Window | 1740*925 aluminum sliding window |
| Door | Steel door | |
One side of this modular building are bedrooms, another side is the public bathrooms.
The walkway and stair is one meter wide. Around 128 people live in this green prefabricated house.
◪1. The unit figure for K house dimension is K. 1k=1.82m |
◪2.K house can be done as 1 floor, 2 floors or 3 floors building. Figures for house with different stories: One floor=3P, two floor=6p, three floor=9p ( 1P=0.95m ). |
◪3. K house is commonly used with qualified waterproof, fireproof （EPS/Rock wool/IEPS/PU sandwich panel）, heat insulation and sound insulation performance. |
◪ 4. K house uses reusable materials and is more environment-friendly compared to traditional buildings. It can be assembled and disassembled 6 times. |
◪ 5.K house is Anti worm and ant. All steel structures are well painted and anti-rust which can be normally used for over 15 years with very limited amount of building wastes. |
◪ 6.K house only requires level concrete floor for the foundation. |
◪ 7. 6 labors constitute one team, which can install areas of more than 300 ㎡ each day. |
K-House 3D model
Material parameters
Main steel：C section steel for column & beam；
Wall panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Roof panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Window：Aluminum sliding window；
Door：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel or steel door；
Ridge capping: 0.326/0.376/0.426mm single steel sheet.
Wind resistance | Grade 11(wind speed≤120 km/h) |
Earthquake resistance | Grade 7 |
Snow load capacity of roofing | 0.6 kn/m² |
Live load capacity of roofing | 0.6 kn/m² |
External and internal wall heat transmission coefficient | 0.35 kcal/m²hc |
Wall permitted loading | 0.6 kn/m² |
Second floor load capacity | 180kg/m² |
Live load of corridor | 2.5kn/m² |
Density of EPS | 12 kg/m² |
Delivery time | Normally 20-25 days |
Container loading | 300-320 m² /HQ |
This prefab house can be used as the dormitory, office, school, canteen, store room, shop, clinic and so on. The materials of the house are very environment-friendly. It can be assembled and disassembled 6 times. For more information about it, welcome to contact us.
Company Features
1. Guangdong WELLCAMP BUILDING MATERIALS CO., LTD is gradually expanding its overseas market prefab houses by increasing production lines.
2. WELLCAMP, WELLCAMP prefab house, WELLCAMP container house has powerful manufacturing prefab houses china abilities.
3. Guangdong WELLCAMP BUILDING MATERIALS CO., LTD is committed to building the world's first brand among comparable products! Contact! Guangdong WELLCAMP BUILDING MATERIALS CO., LTD will help you better increase your benefits. Contact! The outstanding quality of prefab house kits is our commitment.
Fast build Prefab wooden house made in China
Specifications:
1.Material: spruce,fir or pine wood
2.sizes: DEM or OEM
3.Easy to assemble and disassemble
1).Item No.:EY-L002
2).Material: Russian pine or SPF wood
3).Size:Can be according do customer demand.
4)Thickness of the wall:35mm/36mm/47mm/50mm /70mm ,90mm,ect. Floor thickness:23mm or 28mm
Roof thickness:18mm
5).Material of roof: Super asphalt fiber-glass reinforced tile (water proof)
6).Packing: Every part of this item is strapped separately by poly strip
7).Other information: The structure of the wooden house is strong enough to stand wind and earthquake. Since it has lock nature, not only firm, but also simple and easy to assemble. It generally need only two people to finish the assembly work, and has good waterproof performance. Its sake is for living and entertaining, which is very popular in Europe and America.
4,Packages:
5,Foundation:
